mappVision帮助助手 > 机器视觉帮助 > mapp Vision > 用例 > OCR - 识别和读取字符 预配置的 OCR 字体 制药 |
OCR 字体 Pharma 可用于读取以 Arial、OCR-B 和其他制药行业常用字体打印的字符。
该 OCR 字体不包含小写字母。
可用的特殊字符: - / . ( ) :
可使用以下具有不同符号集的 OCR 字体:
带有拒绝级别的 OCR 字体名称 |
无剔除类别的 OCR 字体名称 |
|
---|---|---|
0-9, A-Z, special characters |
Pharma_Rej |
Pharma_NoRej |
0-9 |
Pharma_0-9_Rej |
Pharma_0-9_NoRej |
0- 9, special characters |
Pharma_0-9+_Rej |
Pharma_0-9+_NoRej |
0-9, A-Z |
Pharma_0-9A-Z_Rej |
Pharma_0-9A-Z_NoRej |
图 药品标签示例
OCR font Pharma can be used to read characters printed in fonts such as Arial, OCR-B and other fonts typically used in the pharmaceutical industry.
This OCR font does not contain lowercase letters.
Available special characters: - / . ( ) :
The following OCR fonts with different symbol sets are available:
Name of the OCR font with rejection class |
Name of the OCR font without rejection class |
|
---|---|---|
0-9, A-Z, special characters |
Pharma_Rej |
Pharma_NoRej |
0-9 |
Pharma_0-9_Rej |
Pharma_0-9_NoRej |
0- 9, special characters |
Pharma_0-9+_Rej |
Pharma_0-9+_NoRej |
0-9, A-Z |
Pharma_0-9A-Z_Rej |
Pharma_0-9A-Z_NoRej |
Fig.: Examples of pharmaceutical labels
